Network Architecture and Design

One of the most critical aspects to the overall efficiency and effectiveness of your network is the architecture and design. Our network architects hold the highest level of technical certifications across multiple vendors.

A discovery exercise will be undertaken to ensure a full understanding of the existing network infrastructure and configuration. Any Issues will be highlighted for remediation.

Once complete, the new solution will be designed. The documented output will include

High-Level Design documentation outlining the solution and its integration into the existing environment.
Requirements met table
Z
Low Level Design documentation including baseline configuration.
Topology diagram pack (L2 / L3 / Routing)
N
Wiring schematic (L1)
IP Addressing schema
Bill of Materials and ROM cost
Advice on Order of implementation for minimal disruption
Change control

After the initial design phase, a presentation of the solution design will be made to the organisation decision makers.
